Copper nut leads,small size,easy installation.
Plastic packaging,sealed with resin.
High-frequency current carrying capability.
High pulse current，high dv/dt withstand capability.
Low ESL and ESR.
| Operating temperature range | Max.Operating temperature.,Top, max : +105℃ Upper category temperature: + 85℃ Lower category temperature : - 40℃ |
| Capacitance range | 1μF~8μF |
| Rated voltage | 1200V.DC - 2000V.DC |
| Cap.tol | ±5%(J) ; ±10%(K) |
| Withstand voltage | 1.5UN /60s |
| Dissipation factor | tgδ≤0.001 f=1kHz |
| lnsulation resistance | Rs×C≥5000s（at20℃ 100V.DC 60s） |
| Withstand strike current | See the specification sheet |
| Irms | See the specification sheet |
| Life expectancy | 100000h（Un ; θhotspot ≤85℃ ) |
| Reference standard | IEC61071 |
Housing Shape
Film Capacitors Are Cylindrical Plastic Shells, Dry Design, No Liquid Filling, Safe And Reliable, Suitable For A Variety Of Environments.
Long Life
Ultra-Long Life (> 100,000 Hours): Can Work Stably For A Long Time In High-Frequency Applications, Long Life, Reduce Maintenance Frequency And Cost.
Stabilize
Excellent Long-Term Stability: Film Capacitors Maintain Stable Capacitance In Long-Term Use, Suitable For High-Precision, Low-Loss Applications.
